SAE J1453/2_201305
Specification for O-Ring Face Seal Connectors: Part 2 - Requirements, Dimensions, and Tests for Steel Unions, Bulkheads, Swivels, Braze Sleeves, Braze-on Tube Ends, Caps, and Connectors with ISO 6149-2 Metric Stud Ends and ISO 6162 4-Bolt Flange Heads.
SAE International , 05/14/2013
$71.00
$141.00
The three parts of SAE J1453 cover material, dimensional, and performance requirements of steel O-ring face seal (ORFS) connectors for tubing and the O-ring face seal interface and nut portion of hose stem assemblies for nominal tube diameters of 6 mm through 38 mm and for nominal hose diameters 6.3 mm through 38 mm. SAE J1453-2 covers the requirements for "metric based" O-ring face seal connectors to metric stud ends along with the associated adapters, bulkhead and union connectors. Metric hex wrenching flats are used throughout this standard.
Product Information
Published:
05/14/2013
File Size:
1 file , 1.6 MB
Language:
English
Note:
This product is unavailable in Ukraine, Russia, Belarus
SAE J1453/2_201504
$80.00
SAE J1453/2_201305
$71.00
